Cisco Unified IP Conference Station 7936

Cisco Unified IP Conference Station 7936:

The Cisco Unified IP Phone family provides industry-leading levels of integrated business functionality and converged communications features beyond today's conventional voice systems—surpassing competitive offerings. Cisco Systems continues to deliver one of the industry's best end-to-end data and true voice over IP (VoIP) solutions, offering the most complete, stylish, and feature-rich IP phones to enterprise and small to midsize customers.

The Cisco Unified IP Conference Station 7936 combines state-of-the-art speakerphone conferencing technologies with award-winning Cisco voice communication technologies. The net result is a conference room phone that offers superior voice and microphone quality, with simplified wiring and administrative cost benefits. A full-featured, IP-based, hands-free conference station, the new Cisco Unified IP Conference Station 7936 is designed for use on desktops, conference rooms, and in executive suites.

The Cisco Unified IP Conference Station 7936 offers improvements over the existing Cisco Unified IP Conference Station 7935 with external microphone ports, optional external microphone kit, newly audio-tuned speaker grill, and a new backlit liquid crystal display (LCD) display. The optional microphone kit includes two microphones with six-foot cords. This places microphones across a 12-foot area, effectively expanding a suggested conference room size of 20 feet by 30 feet. The new backlit LCD display improves visibility in low light conditions. The display font size is also adjustable for improved distant viewing.

The Cisco Unified IP Conference Station 7936 easily joins a Cisco Catalyst® 10/100 Ethernet switch port with a Cisco RJ-45 cable connection, and configures itself to the IP network via the Dynamic Host Control Protocol (DHCP).

The Cisco Unified IP Conference Station 7936 offers exceptional voice quality—virtually eliminating echoes, reverberations, and truncated words to help deliver a more natural conversation. It features superb sound quality with a digitally tuned speaker and three microphones that minimize background noise, allowing conference participants to move around the room while speaking. Connecting two optional extension microphones to the base unit enables both voice coverage for larger rooms and enhanced speaker volume output.

In addition to the regular telephony keypad, the Cisco Unified IP Conference Station 7936 provides three soft keys and menu navigation keys that guide a user through call features and functions. The Cisco Unified IP Conference Station 7936 also features a pixel-based LCD display, which exhibits the date and time, calling party name, calling party number, digits dialed, and feature and line status.

Features and Benefits:

The Cisco Unified IP Conference Station 7936 provides the following:

Feature	Benefit
Standard business telephony features	Includes call hold, call transfer, call release, mute, conference ("ad-hoc" and "meet-me" conferencing, park, and pick up.
Feature updates	Facilitates Cisco Unified CallManager software upgrades along with advances in system capabilities.
Full-duplex operation	Permits natural, two-way conversations without clipping or distortion; the system automatically adapts to changes in the acoustic conditions of the room using state-of-the-art acoustic technology.
Integrated keypad	Eliminates the need to receive and place calls on a separate telephone.
360-degree room coverage	A powerful, digitally-tuned custom speaker and three sensitive microphones provide uniform coverage of small-to-midsize conference rooms or offices.
Single cable design	Reduces clutter on the tabletop by combining a single cable from the power interface module (PIM) cable with network and power.
Simple to install	Configures easily with Cisco Unified CallManager.
Freedom from special end-user training	Works like a regular telephone.
Dynamic Host Configuration Protocol (DHCP)	Auto address configuration to the IP network.
Cisco Discovery Protocol for Cisco Unified IP Conference Station 7936 to Cisco Catalyst switch port discovery	Provides powerful protocol for E911 services, phone tracking, and asset/theft management.
Auto configuration of phone number, software images, and personalized settings	Simplifies installation, reconfiguration, and future feature enhancements such as Web browsing capabilities.

The Cisco Unified IP Conference Station 7936 uses a single 10/100BaseTx Ethernet LAN connection to the network via a RJ-45 cable interface.

The Cisco Unified IP Conference Station 7936 also features:

• Convenient volume control buttons
• Five user-adjustable ring tones
• G.711 (A-law and µ-Law) and G.729a audio compression
• IP address assignment —DHCP client or statically configured
• Comfort noise generation and voice activity detection
• Web and LCD-based configuration
• Local 20 entry directory

This product also features settings for:

• Display contrast
• Ring type
• Network configuration
• Call status

Technical Specifications:

Cisco Unified IP Conference Station 7936 Specification
Physical Specifications
Audio bandwidth	300 to 3500 Hz
RMC	Speaker volume: 86.5 dB peak volume at 0.5 meters
Recommended room conditions	Closed offices and conference rooms up to 20 feet by 30 feet in dimension without major glass or ceramic surfaces and with normal background air-conditioning noise. (Significant echoes need to be less than one-eighth of a second in duration.)
Firmware updates	Download from Cisco Unified CallManager
Dimensions (H x W x D)	12.5 x 12 x 2.25 in. (31.5 x 30.2 x 5.7 cm)
Weight	1.75 lb (0.8 kg)
Covering	Acrylonitrile butadiene styerene (ABS) plastic in textured Cisco gray color
Power interface	PIM provides power interface and network connection
Temperature Ratings
Operating temperature	32 to 104°F (0 to 40°C)
Relative humidity	20 percent to 85 percent (non-condensing)
Storage temperature	-22° to 131° F (-30° to 55° C)
Certification
Regulatory Compliance	CE marking
Safety	UL 1950 CAN/CSA-C22.2 No. 950 EN 60950 IEC 60950 AS/NZS 3260
Electromagnetic compatibility (EMC)	FCC Part 15 (CFR 47) Class B ICES-003 Class B EN 55022 Class B CISPR22 Class B AS/NZS 3548 Class VCCI Class B EN55024

Documentation:

Download the Cisco Unified IP Conference Station 7936 Datasheet (PDF).
